Mishimoto 2012-2016 BMW F22/F30 Intercooler (I/C ONLY) – Silver

Description

Part #: misMMINT-F30-12SL

Make your Ultimate Driving Machine even more ultimate with the addition of the Mishimoto BMW 2012-2016 F22/F30 Chassis Performance Intercooler! From the factory, the N20/26 and N55 engines are a prowess of German engineering, but the stock intercooler unit poses as a weak link for your turbocharged Bimmer. The tube-and-fin design coupled with plastic end tanks makes for the perfect environment for heat to set up residence and throttle the power of your 2, 3, or 4-series, especially for those running a tune.

Mishimoto is here to unlock the full potential of your N20/26 and N55 engines withtheir Performance Intercooler specifically designed for the F22/F30 chassis. Their unique 6” thick step-core design adds a 115° angle to the top section to allow for additional charged air cooling without fully obstructing other heat exchangers. Tubes and fins are a thing of the past with this design as Mishimoto engineered their intercooler with a bar-and-plate construction, optimizing this intercooler for heat dissipation with minimal pressure drop.

Coupled together, their features were able to drop intercooler outlet temperatures by 45°F, and add 10 whp and 8 wtq all on the stock tune of a 2017 M2 test vehicle. The BMW F22/F30 Performance Intercooler is available in silver or black and also includes the Mishimoto Lifetime Warranty.

Features & Specifications:

• Direct fit for the 2012-2016 BMW F22/F30 Chassis
• Patent Pending
• 6” thick, angled step-core design optimized for maximum flow without fully obstructing other heat exchangers
• Max power gains of 10 whp and 8 wtq on stock tuning
• Drops intercooler outlet temperature by 45°F on stock tuning
• Optimal core design for maximum cooling efficiency with minimal pressure drop
• Intercooler core volume increased by 96%
• External fin surface area increased by 130%
• Header plate includes shroud specifically designed to seal against curved factory crash beam
• Retains factory quick-disconnect fittings for compatibility with stock piping
• Available in silver or black
• Mishimoto Lifetime Warranty
